Abstract

Optimum Matched Filter (Transfer Function)

(Nested Processes ... Each Process controlled by a Solver)

Problem Description

The transfer function H(s) is the Laplace transform of the output signal Yout(s)* divided by the Laplace transform of the input signal Yin(s)*: that is H(s)=   where each signal's transform is assumed to be a ratio of polynomials.  Thus, H(s) can likewise be stated in the form:

Equation 2.1  Generalized H(s)

Assuming the numerator and denominator can be factored, yields H(s) in the general form

Equation 2.2  Factored Transfer Function

where each Zi is known as a "zero" and the Pi as a "pole" of the transfer function.  Zi and Pi are complex points in the Laplace domain.

A realizable transfer function must have poles and zeros with their conjugate points.  That is, poles and zeros come in pairs.  If a pole or zero is located at the complex point si + jwi, then its conjugate is located at si - jwi.  Thus, a generalized transfer function is stated as

Equation 2.3  Generalized Transfer Function H(s)

Given n-data points from a Bode plot (see Figure 2.1 below) that define the mainlobe of the desired transfer function, find the optimal Pole/Zero constellation such that H(s) has equal sidelobe peak amplitudes in a Bode plot and curve fits the given data in the mainlobe.

Bode Plot: Mainlobe with 3 Sidelobes

ooo

For more, read attached PDF file.

Links:    Slide Show    Website    Download

Your Turn!

Have a Filter design to solve?  Please state it here and use graphs, pictures, etc. to get your problem well stated and understood by those reading it.
